Multi-cylinder Hydraulic Cone Crusher

Multi-cylinder Hydraulic Cone Crusher are a new type of cone crushers developed and optimized by our company on the basis of introducing and absorbing European and American hydraulic cone crusher technologies. Compared with other cone crushers, it boasts low energy consumption, large crushing force, high reliability, large production capacity, high degree of automation, simple operation and maintenance, good product shape, low cost of wearing parts, etc.

Hydraulic cone crusher can crush materials of above medium hardness, such as iron ores, copper ores, non-ferrous metal ore, limestone, quartz, granite, gritstone, etc. And it is widely used in metallurgy, building, hydropower, transportation, chemical industry, etc. When used in a stone production line, it can be used as secondary, tertiary or quaternary crushing.

The Features of Multi-cylinder Hydraulic Cone Crusher

1. High efficiency. Multi-cylinder hydraulic cone crusher uses a fixed spindle and ball shaft reciprocal optimized structure, which makes the efficiency higher 5%~15% than the old spring cone crusher.

2. Large production capacity. The multi-cylinder hydraulic cone crusher has the perfect combinational design of crushing stoke, crushing speed and crushing cavity, which makes the production of single-cylinder cone crusher be higher 35%~60% than old spring cone Crusher under the same cone big end diameter.

3. High-quality stones. The multi-cylinder hydraulic cone crusher adopts special crushing cavity and laminating crushing principle, which makes the cube proportion of final products increase significantly and reduces needle-shaped stones. So the particles are more even.

4. More stable operation. When the iron ore and other hard materials that cannot be crushed enters the multi-cylinder hydraulic cone crusher, the over iron protection device will automatically release them and then immediately reset.

5. Multi-dotted body of hydraulic and lubrication control system, which ensures the dual protection of the bearing lubrication and overload protection.

Structural Advantages of Cone Crusher

Cone crusher parts mainly include a frame, a horizontal axis, a balanced wheel, an eccentric sleeve, an upper crushing wall (fixed cone), a low crushing wall (movable cone), hydraulic coupler, lubrication system, hydraulic system, and control system.

Working Principle of Cone Crusher

The entire crushing is completed by a fixed cone and the cyclic-moved cone. When a multi-cylinder hydraulic cone crusher works, the horizontal axis is driven by a motor with a triangle-belt and a wheel. Two different sized wheels make the eccentric bushing rotate through the axis. With the effect of the eccentric bushing, the cone axis moves in a cranking motion, which results in a regular near-and-far between the fixed cone and the crushing wall. Here, materials get constantly pressed and impacted until reaching the required size. Qualified products fall down and are blenched out through the outset.

Technical Data of Multi-cylinder Hydraulic Cone Crusher
